Principal dimensions | Basic load ratings | Limiting speed | Designation | ||||
Dynamic | Static | Grease | Oil | ||||
d | D | B | Cr | Cor | RPM | RPM | |
mm | KN | r/min | |||||
85 | 150 | 28 | 158 | 192 | 3600 | 4500 | NJ217 |
100 | 215 | 47 | 365 | 425 | 2600 | 3200 | NJ320 |
25 | 62 | 24 | 53.2 | 54.5 | 9000 | 12000 | NJ2305 |
25 | 52 | 15 | 27.5 | 26.8 | 11000 | 14000 | NU205 |
25 | 52 | 15 | 27.5 | 26.8 | 11000 | 14000 | NU205E |
120 | 215 | 40 | 322 | 422 | 2200 | 3000 | NU224 |
140 | 250 | 42 | 302 | 415 | 1800 | 2400 | NU228 |
25 | 52 | 15 | 28.8 | 27.1 | 11000 | 14000 | NU 205M |
25 | 52 | 15 | 30.6 | 29.3 | 10500 | 13500 | NJ 205 EF1 |
25 | 52 | 15 | 30.6 | 29.3 | 11000 | 14000 | NJ 205 ETN1 |
25 | 52 | 15 | 28.8 | 27.1 | 11000 | 14000 | NJ 205 EM |
25 | 52 | 15 | 28.8 | 27.1 | 11000 | 14000 | NU 205 EM |
25 | 52 | 18 | 37.8 | 40.2 | 2200 | 4500 | NU 2205 V/C9 |
25 | 62 | 17 | 36.9 | 32 | 9500 | 12000 | NJ 305 E |
25 | 62 | 17 | 30.6 | 26.6 | 9500 | 12000 | NJ 305 |
25 | 62 | 17 | 38 | 37 | 9500 | 12000 | NU 305 M |
25 | 62 | 24 | 50.5 | 49.5 | 9000 | 11000 | NJ 2305M |
25 | 62 | 24 | 58.4 | 62.2 | 2200 | 4500 | NCL 2305 V |
30 | 72 | 19 | 51.2 | 48 | 9000 | 11000 | NU 306 EM |
30 | 62 | 16 | 34.3 | 21.7 | 9500 | 12000 | N 206 E |
30 | 62 | 16 | 34.3 | 21.7 | 9500 | 12000 | NJ 206 E |
30 | 62 | 16 | 34.3 | 21.7 | 9500 | 12000 | NU 206 E |
30 | 62 | 16 | 26.5 | 25.3 | 9500 | 12000 | N 206 |
30 | 62 | 16 | 26.5 | 25.3 | 9500 | 12000 | NU 206M |
30 | 62 | 16 | 32.9 | 29.7 | 9500 | 12000 | NU 206EM |
30 | 62 | 16 | 26.5 | 25.3 | 9500 | 12000 | NU 206Q1PS |
30 | 62 | 16 | 26.5 | 25.3 | 9500 | 12000 | NJ 206M |
30 | 62 | 16 | 36.1 | 34.7 | 10810 | 13620 | N 206 ETN1 |
30 | 62 | 16 | 36.1 | 34.7 | 10810 | 13620 | NU 206 ETN1 |
30 | 62 | 16 | 36.1 | 34.7 | 10810 | 13620 | NJ 206 ETN1 |
